TE 1000-AVR Concrete breaker
Versatile TE-S breaker for demolishing concrete floors and occasional wall chiselling
- Working direction: Floor, Wall
- Tool chuck type: TE-S
- Weight according to EPTA-Procedure 01/2003 without battery: 12.5 kg
Technical Data
Working direction
Floor, Wall
Tool chuck type
TE-S
Weight according to EPTA-Procedure 01/2003 without battery
12.5 kg
Single impact energy
26 J
Full hammering frequency
1950 impacts/minute
Max. chiselling performance
7800 cm³/min
Dimensions (LxWxH)
710 x 141 x 305 mm
Triaxial vibration for chiselling in concrete
5.9 m/s² 1
Dust removal system available
TE DRS-B
A-weighted emission sound pressure level
85 dB (A) 2
- According to the applicable product standard (see the Operating Instruction for more details)
- According to the applicable product standard (see Operating Instruction for more details)
Features & Applications
Features
- High versatility – in-line design for floor breaking and ergonomic side handle for occasional wall breaking
- Maintenance-free brushless SR motor and triple-chamber lubrication system for longer service intervals and tool lifetime
- Active Vibration Reduction (AVR) makes the tool less tiring to use – helping to increase daily productivity
- Detachable supply cord for quick and easy replacement of damaged/broken cords on the jobsite
- Optional TE DRS-B dust removal system, which collects up to 95% of dust
Applications
- Demolishing concrete and masonry at floor level or below waist level
- Renovating floors of all kinds
- Removing tiles, bushing and compacting
- Corrective chiselling such as adjustments to door and window openings
For approval or certificate information, please see individual items.
Services
Hilti Tool Service
- Servicing is free of charge for up to 2 years, including wear and tear, pick-up and delivery
- 3 or free: get the tool serviced and cleaned in 3 days flat or there is no charge
- After the no-cost period, repair costs are capped at max. 40% of the price of an equivalent new tool
- 3-month no-cost period after each repair
